Full-size dishwashing.
In just 410 millimetres of installation height.
The DishDrawer™ brings a genuine dishwasher into installation spaces that rule out conventional appliances — motorhome, yacht, tiny house. It opens like a kitchen drawer instead of a drop-down door and saves the swing clearance that blocks the aisle in narrow layouts.
410 mm
Installation height, single unit
43 dB(A)
Operating noise
6
Place settings per drawer
230 V
Mains or inverter operation
In series production across European vehicle and yacht building
Morelo
Empire Liner · Single DishDrawer
Morelo
Concorde Liner · Single DishDrawer
Hanse
575, 12 m yacht · Double DishDrawer
Bavaria
R series, 10 m motorboat
Further series partners in premium motorhome and yacht building on request.
The approach
We do not simply supply a dishwasher. We make a full kitchen possible where there was never room for one.
For development, engineering and product management: the DishDrawer™ opens like a kitchen drawer instead of swinging out to the front. As the exclusive importer, coolHouse supplies appliances, spare parts and service from a single source — since 2009.
Interactive · Explore in 3D
The DishDrawer™ – from every angle
Rotate, zoom, open the drawer: assess integration, proportions and operation directly on the model – exactly as your end customers will experience the appliance later.
- Panel-ready front – accepts your own decor panel and blends seamlessly into the furniture line
- Compact installation dimensions for tight spaces in motorhome and yacht
- Loads from the top – ergonomic loading without bending, even in cramped spaces
- Fisher & Paykel series quality, built for continuous mobile use
Applications
Built for installation spaces where every centimetre is accounted for.
Two core markets with series references — the same solution scales into every other segment with tight installation space.
Premium motorhomes
Motorhomes
Full-size dishwashing despite a compact layout — with no compromise on payload or living comfort. In series production at Morelo and Concorde.
Yacht and boat building
Yachts
Low weight, quiet operation and a loading principle that stays securely locked even in rough seas. In series production on the Hanse 575 and Bavaria R series.
Technology
The specs your engineering team needs first.
Three configurations cover the vast majority of mobile applications. Full dimensioned drawings, CAD files and data sheets in the Design Kit.
Configurations and installation dimensions
| Model | Configuration | Dimensions H×W×D | Capacity | Typical application |
|---|---|---|---|---|
| DD60SHI9 | Single, Series 9 | 410 × 599 × 571 mm | 6 place settings | Motorhome, sailing yacht, tiny house |
| DD60SHTI9 | Single tall, Series 9 | 454 × 599 × 571 mm | 6 place settings, plates up to 310 mm | Liner class, motor yacht |
| DD60DHI9 | Double, Series 9 | 820–880 × 599 × 571 mm | 12 place settings, 2×6 | Large liner, yacht from 12 m |
All configurations are designed for a customer-supplied furniture front (panel-ready). Series 11 is available in the same installation spaces.
Operating values
| Feature | Value | Relevance for installation |
|---|---|---|
| Noise level | 43 dB(A) | Critical in just a few square metres of living space |
| Water consumption | [Platzhalter: l pro Schublade und Zyklus] | Determines the fresh and waste water tank balance |
| Energy consumption | [Platzhalter: kWh/100 Zyklen] | Basis for battery capacity and charging technology |
| Wash programmes | 6 + 3 modifiers | Fast, Sanitise and Extra Dry |
| Operation | Knock-to-Pause | Knock to pause the wash cycle |
Enough for a first assessment?
CAD files, dimensioned drawings and model-specific data sheets are in the Design Kit — free of charge.
Interactive · Space Check
Does the DishDrawer™ fit your installation space?
Enter the niche height and width — the check instantly shows which configuration fits and how much clearance remains.
Guide values based on the appliance dimensions. Binding installation drawings in the Design Kit.
Request the Design KitOn-board power & connection
The question that comes first in vehicle building.
The DishDrawer™ is a 230-volt appliance. In mobile use it runs on shore power or on an inverter fed from the on-board electrical system — both are proven in motorhome and yacht building.
When sizing the inverter, the inrush current of the heating phase is decisive alongside the rated power draw. We coordinate the sizing on a per-project basis with your electrical engineering team.
Supply voltage
220–240 V
Mains frequency
50 Hz
Current
10 A
Water pressure
100–1000 kPa
Water inlet
3/4″ BSP (20 mm)
Rec. inverter
[Platzhalter: Leistung]
Inrush current
[Platzhalter: A]
Partnership
What matters to an OEM partner beyond the appliance itself.
An appliance in a vehicle is a decision that spans the entire product life cycle.
01
Service in the DACH region
Sales, service and a network of more than 80 authorised workshops in Germany, Austria and Switzerland.
02
Spare parts across the vehicle life cycle
Spare parts supplied directly by coolHouse, with its own spare parts shop.
03
Order volumes
Larger series volumes are well established. coolHouse already works with several OEM partners.
04
Lead times
[Platzhalter: Angabe zur regulären Lieferzeit und zu Rahmenvereinbarungen für Serienabrufe.]
05
Sample unit before series release
Before the decision, we provide a sample unit for real installation and validation in the vehicle.
06
Dedicated contact
No ticketing system: a named contact who knows your project and your series goals.
From enquiry to series production
A clear path — from first contact to the series product.
Five steps proven in vehicle and yacht building.
01
Contact
Request the Design Kit, first call to scope things out.
02
Assessment
Technical assessment in the context of your installation space and on-board power.
03
Sample unit
Real installation and validation in the vehicle or on board.
04
Pilot
Integration into a model series, coordination of front and connection.
05
Series
A permanent solution in the range, with ongoing support.
Free · for technical decision-makers
The OEM Design Kit.
Everything for your internal technical assessment in one package. After you submit, your dedicated contact gets in touch personally — no automated mailing list.
- — CAD files (DWG, DXF, Revit, SketchUp)
- — Dimensioned drawings and installation sketches
- — Technical data sheets per configuration
- — Consumption and noise figures
- — Notes on on-board power sizing
- — Reference images from series projects
Request the Design Kit
In under a minute — straight to your inbox.
Direct line
Let us talk about your project.
Installation space, on-board power, series goals — you speak directly with someone who knows the brand and vehicle building. Response within 2 business days.
